Robot Vacuum Assembly
Stirling EE-9248 Robot Vacuum Rubber Brush Assembly
- 3D Design by Clockspring @Clockspring (https://www.Myminifactory.com)
We appreciate Clockspring to allow us to share your talented design here.
Only 1 design file, 'Rod-core' is showing above and will be downloadable by above Download button.
**However, there are 4 designs. Here are the links to download all design files.**
- rod-core: https://cdn.myminifactory.com/assets/object-assets/5b403b27e5697/threedfiles/rod-core.stl
- socket-flange: https://cdn.myminifactory.com/assets/object-assets/5b403b27e5697/threedfiles/socket-flange.stl
- flexible-brush-segment: https://cdn.myminifactory.com/assets/object-assets/5b403b27e5697/threedfiles/flexible-brush-segment.stl
- bearing-flange: https://cdn.myminifactory.com/assets/object-assets/5b403b27e5697/threedfiles/bearing-flange.stl
Well, this was a fun one! Sometimes it's really evident that different manufacturing methods have different capabilities and limitations, especially when trying to replicate something for 3D FDM printing!
So, this part, which is a rotating rubber brush that had broken in my vacuum cleaner, has a rigid core, a metal pin that sits inside a bearing and suspension bushing, and flexible rubber fins on the outside. Not the most obvious target for a 3D printed alternative, but we can't let that get in the way, right?!
Most importantly, this spare part needed to be easily printable, without supports, and without requiring any particular printer fanciness beyond being able to print flexible filament for the blades themselves.
A few design considerations:
* The rod core needs to be designed to print such that the layers run parallel to the long axis, for strength.
* The flexible blades need to be designed to print such that the layers run perpendicular to the long axis, also for strength.
* Blades need to be held in place such that they can't move with respect to the rod core, or else they'll shift under load during operation.
After a few changes of approach, the design ended up like so:
* Hexagonal central core, for easy printing on its side
* Sleeve-style blades, to be printed in flexible filament, and slipped onto the rod.
* Blades designed as segments, for easier printing.
* Tight press-fit flange end-pieces, printed separately. Where the original had sharp steps, the flanges in this model have graduations and vertical steps, for printability without supports, while still functionally appropriate.
* Incorporation of a cavity for an 10mm M3 bolt. Screwing this bolt all the way into the bearing flange will leave it protruding exactly the right length to take the bearing.
So, there we go, more amazing things we can do with 3D printers!
Ikea Kulla lampshade Tightening Spare Part
A re-design of the small piece of plastic to tight the lampshade of a IKEA Kulla floor lamp.
Mine broken after the lamp fall down.
3D Design by spyfox.3d.printing @spyfox.3d.printing (https://www.Myminifactory.com)
We appreciate 'spyfox.3d.printing' to allow us to share your talented design here.
Shower head holder
- Time to do: 150 minutes
- Material Quantity: 31.8 g
- Dimensions: 62mm x 61mm x 34mm
- Technology: FDM
- Complexity: Easy
- Support Free: YES
3D Design by Anton @Ravenor (https://www.Myminifactory.com)
We appreciate Anton to allow us to share your talented design here.
3d printable pegs
This is designed in Autodesk Fusion 360 - Made on Robo 3D R2 with Robo 3D Filament
Ready to use straight from the Printer
Cleaning Appliance - Washing Line
Model Number - Generic (Any)
3D Design by Mark Chester @mark.chester (https://www.myminifactory.com)
We appreciate Mark to allow us to share your talented design here.
Dyson adapter to flex hose
This is an adapter to connect a 1/2" flexible hose to a Dyson vacuum cleaner.
This allow to reach difficult corners and places.
3D Design by Carlo Franciscone @daGHIZmo (https://www.Myminifactory.com)
We appreciate Carlo to allow us to share your talented design here.
